EM-07-250D-DIN Multifunction Power Meter (With CT, DIN Rail Type, 10–250A Range)

EM-07-250D-DIN Multifunction Power Meter (With CT, DIN Rail Type, 10–250A Range)

The EM-07-250D-DIN is a high-precision, DIN-rail-mounted multifunction digital power meter designed to measure and monitor key electrical parameters including voltage, current, frequency, and apparent power. With integrated current transformers (CTs) and RS485 Modbus RTU communication, it provides reliable performance for industrial and commercial energy monitoring applications.

Inquiry Now

Description

EM-07E-DIN ( User Manual ) ➜

The EM-07-250D-DIN allows for real-time monitoring of 3-phase voltage and current, showing per-phase apparent power (S) and frequency (F), along with minimum, maximum, average, and demand values. Its 71.5 × 61.5mm glass LCD display offers a sharp, easy-to-read interface, while the menu system is user-friendly and password-protected for secure access.

The meter is equipped with adjustable protections for over/under voltage, current, and frequency, along with phase-to-phase or phase-to-neutral fault protection. It also features phase sequence detection and includes 1 relay output for alarms or automation triggers.

Designed for systems with 3-phase voltage and 3-phase CT inputs, this model supports remote communication via RS485 (Modbus RTU), making it ideal for integration into SCADA or energy management systems. With its included CTs and compact DIN rail form factor, installation is quick and efficient.

Key Features

DIN Rail Mounting – Compact design for seamless panel integration
Glass LCD Display (71.5 × 61.5 mm) – High-visibility interface
Includes Current Transformer (CT) – Ready-to-install monitoring
3-Phase Voltage & Current Measurement
Displays Apparent Power (S) Per Phase
Measures Voltage (V), Current (I), and Frequency (F)
Shows Minimum, Maximum, Average, and Demand Values
Adjustable Protections – Voltage, current, and frequency thresholds
Phase-to-Phase & Phase-to-Neutral Protection
Phase Sequence Monitoring – Ensures proper wiring
RS485 Communication (Modbus RTU) – Enables remote access and control
Password-Protected Menu – Prevents unauthorized configuration
1 Adjustable Relay Output – Ideal for alarms or load control
Measurement Range: 10–250A – Suitable for medium to large loads

Applications

Industrial and commercial energy monitoring
Power distribution panels and switchboards
Load balancing and demand analysis
SCADA and energy management systems
Electrical fault protection and automation

The EM-07-250D-DIN offers a complete, ready-to-deploy solution for precise power monitoring and system protection—ideal for modern, intelligent energy infrastructure.
